COMPACT AUTOMATIC CAPSULE FILLER
NJP-400C Automatic Capsule Filling Machine
Compact automated encapsulation at up to 24,000 capsules per hour, sized for labs and small production rooms stepping up from semi-automatic filling.
View Specs FAQs Request Quote
⚡
24,000 Caps/Hour
Automated output in a compact, floor-saving footprint.
🎯
Tamping-Pin Dosing
Stable, repeatable fill weights across powders and pellets.
🥼
GMP-Ready Stainless
Stainless steel contact parts for clean, compliant production.
🇺🇸
U.S. & Canada Support
Setup guidance and spare-parts support close to home.
Compact automation for labs and small batches
The NJP-400C is the smallest automatic in the NJP range — full automated filling in a footprint that fits tight production rooms and labs. It's the natural step up when hand-filling or a semi-automatic unit can no longer keep pace.
- Up to 24,000 capsules per hour, fully automated
- Runs capsule sizes 000–5 with change tooling
- Smallest footprint in the automatic range (720 × 680 mm)
- Quick changeover between capsule sizes
Technical specifications
| Model |
NJP-400C |
| Type |
Automatic capsule filling machine |
| Output |
Up to 24,000 capsules/hour (≈400/min) |
| Capsule sizes |
000–5 |
| Fill material |
Powder / pellet |
| Dosing |
Tamping pin |
| Power |
110V 60Hz or 220V 50Hz, three-phase (by variant) |
| Construction |
Stainless steel contact parts |
| Compliance |
GMP-ready; CE; FDA & UL documentation available on request |
| Footprint (L×W×H) |
720 × 680 × 1700 mm |
| Net weight |
700 kg |
| Warranty |
1-year warranty |
| Included |
One set of change tooling |
Complete your capsule line
Frequently asked questions
How many capsules can the NJP-400C fill per hour?
Up to 24,000 capsules per hour (about 400 per minute), depending on capsule size and formulation.
What capsule sizes does it support?
Sizes 000 through 5, using change tooling. One tooling set is included; additional size tooling is available on request.
Is the NJP-400C GMP compliant?
It features stainless steel contact parts and GMP-ready construction. FDA and UL documentation is available on request.
What power supply does it require?
Three-phase, available in 110V/60Hz and 220V/50Hz — choose the variant that matches your facility.
Is the machine covered by a warranty?
Yes — the NJP-400C includes a 1-year warranty.
What's included with the machine?
The NJP-400C and one set of change tooling. Additional capsule-size tooling can be added to your order.
Do you provide U.S. and Canada support?
Yes — setup guidance and spare-parts support is available in the U.S. and Canada.
